SAMSUNG 860 EVO Series mSATA 500GB SATA III V-NAND 3-bit MLC Internal Solid State Drive (SSD) MZ-M6E500BW

Brand

SamSung

Products Status

New

Application

Desktop

Series

Samsung 860 EVO

Model

MZ-M6E500BW

Brand	SamSung
Products Status	New
Application	Desktop
Series	Samsung 860 EVO
Model	MZ-M6E500BW
Device Type	Internal Solid State Drive (SSD)
Used For	Consumer
Form Factor	mSATA
Capacity	500GB
Memory Components	V-NAND 3-bit MLC
Interface	SATA III
Controller	Samsung MJX
Cache	Samsung 512GB Low Power DDR4 SDRAM
Max Sequential Read	Up to 550 MBps
Max Sequential Write	Up to 520 MBps
4KB Random Read	QD1: Up to 10,000 IOPS, QD32: Up to 97,000 IOPS
4KB Random Write	QD1: Up to 42,000 IOPS, QD32: Up to 88,000 IOPS
MTBF	1,500,000 hours
Features	Boosted endurance, Enhanced performance, Multiple form factors, Samsung Magician, Smart compatibility, The SSD you trust, Up to 8x higher TBW (Terabytes Written) than the 850 EVO. Feel secure storing and rendering large sized 4K videos and 3D data used by the latest applications., Whatever size your computer needs, there is an 860 EVO for you. Choose among the 2.5-inch size for desktop PCs and laptops, and the SATA-based M.2 (2280) or the mSATA for ultra-slim computing devices.
Power Consumption (Idle)	50 mW
Power Consumption (Active)	Average: 2.5W, Maximum: 4.5W (Burst mode)
Operating Temperature	0??C ~ +70??C
Storage Temperature	-45??C ~ +85??C
Operating Humidity	5% to 95% RH
Max Shock Resistance	1,500G & 0.5 ms (Half sine)
Max Vibration Resistance	20G
Height	4.83mm
Width	29.97mm
