| Embedded Options Available | No |
|---|---|
| Max # of DIMMs | 2 |
| Product Name | Intel NUC 11 Essential Kit – NUC11ATKC2 |
| Graphics Output | DP++/HDMI |
| Max # of Memory Channels | 2 |
| Processor Included | Intel Celeron Processor N4505 (4M Cache, up to 2.90 GHz) |
| M.2 Card Slot (wireless) | 1 |
| Intel Platform Trust Technology (Intel PTT) | Yes |
| Code Name | Products formerly Atlas Canyon |
| Product Collection | Intel NUC Kit with Intel Celeron Processors |
| Internal Drive Form Factor | M.2 SSD |
| Total Threads | 2 |
| Integrated Wireless | Intel Wireless-AC 9462 + Bluetooth 5.0 |
| DC Input Voltage Supported | 19VDC |
| Memory Types | DDR4-2933 1.2V SO-DIMM |
| Application | PC |
| Board Number | NUC11ATBC2 |
| Socket | Soldered-down BGA |
| Brand | Intel |
| Lithography | 10 nm |
| Integrated Graphics | Yes |
| Supported Operating Systems | Windows 11*, Windows 10*, Linux* |
| Chassis Dimensions | 135x115x36mm |
| PCI Express Revision | Gen 3 |
| P/N | NUC11ATKC2 |
| Total Cores | 2 |
| Integrated Bluetooth | Yes |
| M.2 Card Slot (storage) | 1 |
| USB Configuration | 2x front USB 3.2 Gen 1 and 2x rear USB 3.2 Gen 2; 2x USB 2.0 |
| Warranty | 1 Year |
| Audio (back channel + front channel) | 1x 3.5mm stereo out jack, 1x 3.5mm microphone jack |
| Packaging Details | BOX |
| Max Memory Size (dependent on memory type) | 32 GB |
| # of USB Ports | 6 |
| USB Revision | 3.2 Gen 2 / 3.2 Gen 1 / 2.0 |
| Intel HD Audio Technology | Yes |
| # of Internal Drives Supported | 1 |
| ECC Memory Supported | No |
| Included Storage | Optional 64GB eMMC |
| Integrated LAN | 10/100/1000 |
| Products Status | New |
Intel NUC 11 Essential Kit-NUC11ATKC2
Other features: Intel NUC Kit with Intel Celeron Processors DP++/HDMI
| Embedded Options Available | No |
|---|---|
| Max # of DIMMs | 2 |
| Product Name | Intel NUC 11 Essential Kit - NUC11ATKC2 |
| Graphics Output | DP++/HDMI |
| Max # of Memory Channels | 2 |
